R1001 Curved Glass Railing System
Modular, segmented system that provides exceptional design flexibility for curved and non-linear applications. Ideal for high-rise buildings, shopping mall galleries, and curved balcony applications.
Product Overview
Glass Railing Systems by Asay Global are developed to support innovative architectural concepts while ensuring high safety standards and visual continuity. Designed for complex geometries and curved layouts, these systems allow architects to translate creative ideas into functional, buildable solutions across residential and commercial projects.
The R1001 Curved Glass Railing System by Asay Global is a modular, segmented system that provides exceptional design flexibility for curved and non-linear applications. Thanks to its sectional structure, R1001 enables smooth radius transitions and precise alignment, making it an ideal solution for high-rise buildings, shopping mall galleries, and curved balcony applications. The system combines structural reliability with architectural freedom, allowing glass to follow organic forms without compromising safety or stability.
Technical Images
Technical Specifications – R1001
Base Profile Dimensions
92 × 100 mm (without cover)
Segment Lengths
140 mm, 280 mm
Compatible Glass Types
10+10 mm laminated glass, 8+8 mm laminated glass
Glass Embedment Depth
76 mm
Optional Accessories
Floor leveling plate available
Maximum Railing Height
110 cm (Measured from finished floor level, excluding top profile and handrail)
